Pampers Pure Protection Training Underwear Production line

$129 - 999999 /Set/Sets

Payment Type:

L/C,T/T,D/P,D/A,Paypal

Incoterm:

FOB,CIF,EXW,DDP

Min. Order:

1 Set/Sets

Transportation:

Ocean

Port:

Guangzhou,China

Contact Now

Product Description

Product Attributes
Supply Ability & Additional Information
Packaging & Delivery

< >

Overview

Product Attributes

Brand: Xingshi Machinery

Place Of Origin: China

Status: New

Video Factory Inspection: Provided

Mechanical Test Report: Provided

Marketing Type: New Product 2020

Core Component Warranty Period: 1 Year

Warranty Period: 1 Year

Brand: Xingshi Machinery

Overall Size: 35x8x4.5（M）

Machine Size: 30x6x3.5（M）

Design Speed: 300-100tablets/min

Product Yield: ≥97%

Powere Source: 380V，50Hz

Machine Capacity: about 400KW

Air Pressure: 0.6—0.8MPa

Machine Weight: about 80T

Supply Ability & Additional Information

Productivity: 100000sets/month

Transportation: Ocean

Place of Origin: Guangzhou, China

Supply Ability: 100000sets/month

Port: Guangzhou,China

Payment Type: L/C,T/T,D/P,D/A,Paypal

Incoterm: FOB,CIF,EXW,DDP

Packaging & Delivery

Selling Units:: Set/Sets

Production line configuration

• Product size: M: 450×410mm L: 480×410mm XL: 510×410mm XXL: 530×410mm

• Product structure: medium and thick type: anti-side leakage non-woven fabric (inside and outside), surface non-woven fabric A, surface non-woven fabric B (reverse coated core), upper toilet paper, straight strip cotton core with deflector + SAP mix, lower toilet paper, deflector layer non-woven fabric (short cut), PE bottom film (positioning cut), hourglass rubber band, three-dimensional protective rubber band, belt inner non-woven fabric, belt outer non-woven fabric, waist rubber band, S rubber band, mark pattern sticker (positioning cut).

• Control system: PLC control, using touch screen to operate man-machine interface, equipped with high-definition TV monitor

• Transmission system: full servo, synchronous belt, flat belt using imported products, key parts using imported bearings.

• Tension system: equipped with tension unwinding system, constant tension control and storage mechanism, material correction system. This constant tension system ensures stable material reception at full speed, minimizes the impact on the tensile force of the material, and reduces the number of shutdowns.

•Safety system: the operating surface is equipped with safety protection devices and emergency stop switches, safety signs, the rear transmission is equipped with safety cables, and the high-audio fan adopts sound insulation or muffling devices.

• Guiding system: BST guiding device "optional"
